Αποσυμπιεστής-σφιγκτήρας

SCHLEICHER RMS Vario-12-70/9 / HES-12-650

Material width: 100 - 450 mm
Material thickness: 1.0 - 14.0 mm
Coil weight: 10.0 t
Coil inner diameter: 470 - 520 mm
Coil outer diameter: 1100 - 2000 mm
Number of straightening rollers: 12
Hjdjvuugiopfx Abzoff
Straightening roller diameter: 2×70 / 2×96 / 8×127 mm
Number of feed rollers: 2
Feed roller diameter: 160 mm
Min. material width: 100 mm
Speed: 15 m/min
Drive power: 75.0 kW
Decoiler weight: 6.4 t
Straightener weight: 12.8 t
Space requirement decoiler (WxDxH): 3.1 × 1.4 × 3.7 m
Space requirement straightener (WxDxH): 2.5 × 3.4 × 2.7 m
Straightener RMS Vario-12-70/96/127-450
with steplessly adjustable drive, driven straightening rollers, support rollers, upper straightening beam hydraulically liftable, hydraulic entry wedge, hydraulically extendable scrap shear wedge
Decoiler HES 12-650
with steplessly adjustable feed drive, pneumatic overrun brake, hydraulic pressure roller (motor driven), hydraulic central expansion, hydraulic loading saddle, hydraulically operated loop bridge, strip loop control via ultrasound, hydraulic head shear HSO 150-0450
Working direction: from left to right
As is, as it stands and lies, WITHOUT commissioning – Video from owner prior to dismantling available
