εναλλάξιμες βάσεις κοπής (2 τεμ)

COMEC 1.650 x Ø 165 mm

Έτος κατασκευής: 1980, κατάσταση: καλή (μεταχειρισμένη), πλάτος ταινίας: μέγ. Πάχος ταινίας 1.650: μέγ. Άξονας λεπίδας 3 mm speed: ταχύτητα 165 mm: μέγ. 150 m / λεπτό Nwedegrylqspfx Amrsn

Κατάσταση: γενικά ανακατασκευασμένο (μεταχειρισμένο), Έτος κατασκευής: 2016, Slitter Inox 1500x3, manufactured by SAMO OCEMI Fully refurbished in 2016. Technical Specifications Minimum thickness: 0.4 mm Maximum thickness: Up to 4 mm with Rm 400 N/mm2 | Up to 3 mm with Rm 700 N/mm2 Coil width: max. 1,540 mm Maximum coil weight: 16 t Direction: left to right Speed: up to 150 m/min Scope of supply: · Coil car, hydraulic, floor-mounted · Hydraulic expanding decoiler with 28 kW DC motor, 717 rpm, 2,200 rpm, for dynamic braking and energy recovery. Fixed position. · Disc brake. · Powered pinch roller. · Paper re-coiler. · Alignment unit. · Coil opener with telescopic table. · Feed unit with entry pinch roller and 3-roll straightener. · Motorized centering unit with 3 polyurethane leveler rollers. · PVC film applicator (new in 2017) · Slitting head, shaft diameter: 200 mm DC motor 72 kW 780–2,652 rpm + holding brake. · Carousel-type knife loader – double arm. · DC motor for tension roller: 23 kW, 1,960 rpm + holding brake. · Movable scrap table with scrap conveyor. · Scrap winder, single drum 600x600 mm. 15 kW AC motor with inverter. · Looping bypass table · Braking cart (mobile) featuring: * Double separator roller * Deburring roller (new 2017) * Felt press * Braking rollers with 33 kW DC motor, 2,550 rpm, for strip tension control and energy recovery * Cross-cutting shear (cut-to-length shear) * Deflector roller Nsdpfjymcmfex Amrown · Rewinder with hydraulic expansion and separator arm with automatic lifting system. 114 kW DC motor, 800–2,400 rpm + holding brake. · Coil discharge car, floor-mounted, with pressing arm. · 4 x 20 t motorized turnstile arm · Electrical equipment (NEW 2016). Power supply: 3x380V Includes: Control cabinet dimensions: 5,600 x 600 mm, with Siemens S7-300 PLC. 3 operator panels. Main cabinet with Siemens HMI touch screen. · Hydraulic equipment. Oil/air-cooled hydraulic unit. Manifolds with solenoid valves on each machine, 24V DC. · Complete safety fencing, mechanical/optical. · Slitting tools (approx. 160 knives, spacers, separator discs, etc.). Documentation: Foundation drawings Wiring diagrams Hydraulic schematic PLC and HMI software CE Declaration of Conformity Summary: Minimum thickness: 0.4 mm Maximum thickness: Up to 4 mm with Rm 400 N/mm2 | Up to 3 mm with 700 N/mm2 Maximum coil width: 1,540 mm Maximum coil weight: 16 t Speed: up to 150 m/min Direction: left to right

Έτος κατασκευής: 1980, κατάσταση: καλή (μεταχειρισμένη), πλάτος ταινίας: μέγ. Πάχος ταινίας 1.650: μέγ. Άξονας λεπίδας 3 mm speed: ταχύτητα 165 mm: μέγ. 150 m / λεπτό Nsdpfx Aogrylmjmrjwn
