Αυτόματο CNC για κατασκευή παλετών

Sysmathick RPA9 + Stapler

No. 3256

CNC Automated Pallet Production Line Sysmathick RPA9 + Stacker

Used, year of manufacture 2005, system already dismantled

System for assembling wooden components with nailing both from above and below

The RPA9 is a machine with circulating chains designed for the production of pallets in standard dimensions based on four templates (max. 1600 x 1400 mm LxW)

Operation via touchscreen
Cajdpfx Agsx Dddxe Dsa
Format changeover within a few minutes

Two programming methods:
- digital programming via PC (coordinate input)
- manual programming via touchscreen

Storage capacity for thousands of product variants
Automatic adjustment of head spacing (min. 290 mm)
Positioning accuracy +/- 1 mm
High adjustment speed (1 m/s)
Bridge with nine nailers (top: 3x N58 & 3x N400, bottom: 3x N80)
High nailing frequency (one row with three nails per second)
Enables nailing of multi-level pallets thanks to pneumatic-cylinder equipped heads
Pneumatic clamping of boards during assembly

Minimum pallet size 600 x 300 mm LxW
Maximum pallet size 1600 x 1400 mm LxW
Maximum template size 1700 x 1600 mm LxW
Maximum nailing capacity 1600 x 1400 mm LxW
Maximum pallet height 190 mm
Minimum pallet height 110 mm
Machine output: 60–200 pallets/hour

Sale on behalf of customer, ex location near 51371 Leverkusen, excluding dismantling, transportation, and installation
Dismantling, loading, and transport can be provided by us optional

Specifications and price subject to change and errors excepted

To avoid misunderstandings, an on-site inspection after prior arrangement is recommended and possible

Sale as-is

Technical data, condition description, year of construction, and scope of delivery according to manufacturer’s brochure or previous owner, without guarantee
Interim sale reserved
For used machines, all warranty claims are excluded; sales are made "as seen"
Images and videos are for reference only and do not represent the actual scope of delivery

Payment terms: prices plus statutory VAT, payment before collection or shipping

Delivery terms: ex location
